LEO XDPM370A DEEP WELL PUMP Pam Air Rumar Kolam 水泵 (750W/1HP)

Description

Motor
Single phase/Three-phase, 50Hz/60Hz
Insulation class: 130
Protection class: IP44
Ambient temperature up to 40℃
With thermal overload protection
Copper winding

Power Consumption : 1HP/750W

Voltage : 220V (50Hz)

Inlet – Outlet : 1-1/4″ x 1″ (32mm x 25mm)

Max Flow : 85L/min

Max Head : 80m

Max Suction : 25m

Motor with Full Cooper Winding

Max.liquid temperature :+40C
