Description
Motor
Single phase/Three-phase, 50Hz/60Hz
Insulation class: 130
Protection class: IP44
Ambient temperature up to 40℃
With thermal overload protection
Copper winding
Power Consumption : 1HP/750W
Voltage : 220V (50Hz)
Inlet – Outlet : 1-1/4″ x 1″ (32mm x 25mm)
Max Flow : 85L/min
Max Head : 80m
Max Suction : 25m
Motor with Full Cooper Winding
Max.liquid temperature :+40C
Additional information
Weight | 15 kg |
---|---|
Dimensions | 30 × 30 × 30 cm |
