Brand : LEO
Model : ECHM4-20DE
Power Consumption : 0.75HP
Voltage : 220V
Inlet – Outlet : 1 1/4″ x 1″
Max Flow : 117L/min
Max Head : 17-8m
Max Suction : 8m
Stainless Steel Impeller
Motor With 100% Cooper Winding
Max. liquid temperature :+40C
Features
Copper winding
AISI 304 fabricated shaft
Built in thermal protector
Insulation class: F
Protection class: IP44
Applications
Household water supply
Pipeline pressurization
Industrial and mining
Fish farming and poultry raising
Central air conditioning and healthing circulation
