HIKOKI CORDLESS ROTARY HAMMER DH3628DA

Unleash Cordless Power with the HiKOKI DH3628DA

Experience exceptional drilling and chiseling performance without the limitations of a power cord. The HiKOKI DH3628DA 36V cordless rotary hammer delivers a powerful impact energy of 3.2J, rivaling corded models and ensuring fast, efficient work in concrete, steel, and wood.

Key Features:

• High-Performance Brushless Motor: The long-lasting brushless motor provides superior power, efficiency, and durability, ensuring reliable performance on the toughest jobs.

• 3 Operation Modes: Adapt to any task with three versatile modes:

  • Rotation: For drilling into wood and steel.

  • Rotation & Hammering: For rapid and efficient drilling into concrete and masonry.

  • Hammering Only: For chiseling, chipping, and tile removal.

• User Vibration Protection (UVP): Designed with a dynamic vibration absorber and a low-vibration handle, this tool significantly reduces user fatigue and provides enhanced comfort during extended use.

• Reactive Force Control (RFC): This advanced safety feature stops the motor when the bit is suddenly overburdened, preventing the tool from twisting and reducing the risk of injury.

• 2-Step Speed Control: Easily switch between Normal and Low-speed modes via a simple push-button control panel.   The low-speed mode is perfect for drilling into brittle materials, offering greater control and precision.¹²

• LED Work Light: A bright, high-brightness LED illuminates your work area, providing clear visibility in low-light conditions.

• Auto-Stop Function: The innovative auto-stop function allows you to record a drilling time and then consistently repeat the process, ensuring stable and efficient repetitive drilling.

• One-Push Bit Mounting: A quick and easy one-push action simplifies bit changes, saving you time on the job.

• Compact and Ergonomic Design: The lightweight, L-shaped body is ergonomically designed for comfortable and efficient use, even in tight spaces.

• Dust Extractor Compatible: The tool is designed to be compatible with a separate dust extraction system (sold separately), helping to maintain a clean and safe work environment.

• LED Level: An industry-first LED level feature uses an acceleration sensor to help you achieve perfectly vertical holes (+/-5°), improving drilling efficiency and accuracy.

Applications:

• Drilling anchor holes in concrete and masonry.

• Creating pilot holes for fasteners and plugs.

• Precision drilling in tiles and bricks.

• Concrete chiseling, chipping, and wall chasing.

• Drilling in steel and wood with a suitable chuck adapter.

Specifications:

• Voltage: 36V

• Motor Type: Brushless

• Impact Energy: 3.2J (according to EPTA-Procedure 05)

• Drilling Capacity:

  • Concrete: 3.4 – 28mm

  • Concrete Core Bit: 25 – 50mm

  • Steel: 13mm

  • Wood: 32mm

• No-Load Speed: Normal: 0 – 950/min | Low: 0 – 700/min

• Full Load Impact Rate: Normal: 0 – 4,300/min | Low: 0 – 3,170/min

• Bit Shank: SDS-plus

• Weight (with BSL36A18 battery): Approx. 3.9 kg
